The Build

Patience Metal Fab

This ’92 Mk2 Golf isn’t your average swap — it’s getting the full PMF treatment. Every inch of this chassis has been re-engineered for purpose, performance, and perfection.


PMF ENGINEERING

  • Powertrain: 2004 R32 3.2L VR built for four-digit horsepower
  • Driveline: Custom-fabricated rear cradle + Haldex 4-Motion AWD
  • Chassis: TIG-welded SCCA-spec cage integrated into the suspension
  • Suspension: New rear towers built around custom coil-overs
  • Fabrication: Purpose-built structure — no shortcuts, no filler
Patience Metal Fab

Bobby’s Chop Shop

Custom paint and restoration


Full Raptor coating inside and bottom followed by base/clear. Body was then full masked and cage received base clear followed by cut and polish. Exterior received full bodywork and received detail edge work to accent body lines and help improve reflection. Body gaps tightened to improve fit and finish. Exterior received full cut and polish from 800g to 5000g. Bobby's Chop Shop IG

Top Stitch Auto Upholstery


  • Recaro Trophy XL electric front seats recovered in black leather and centers in Relicate Spirit Of Le Mans Blue/Orange
  • Front and rear door cards recovered in black leather and Relicate Spirit Of Le Mans Blue/Orange
  • Dash covered in black leather with dual color stitching, featuring custom 3D printed bezel with custom controls and AIM digital dash
  • Custom made headliner and carpet
Top Stitch Auto Upholstery IG

Masterpiece Automobile

'Waskly' is a fully custom automotive audio build that merges cutting-edge design, digital fabrication, and audiophile-grade performance..


audio build

  • Front Stage: Focal K2 Power components in 3D-printed sail panels and precision-built kick panels.
  • Rear Stage: Integrated K2 Power enclosure with seamless factory-style fitment.
  • Low End: Dual Focal Utopia M 10″ subwoofers in a down-firing, illuminated enclosure — black leather, plaid accents, acrylic window, and glowing Waskly logo.
  • Power & Control: Helix P-Six Ultimate — active front processing + DSP control Helix P-One — dedicated subwoofer amplification for depth and clarity
Masterpiece Automobile
Waskly R32 Banner Image2
Waskly R32 Banner Image5
Waskly R32 Banner Image3

Thank you to all who've invested their time and talent to bring this dream to reality.

Featured at SEMA 2025

SEMA

Spec

Engine

3.2L VR6 FROM MK4 R32 BUILT BY SCHIMMEL PERFORMANCE CAPABLE OF 1000+HP
  • ECU Masters Black
  • Mahle low compression pistons
  • I-beam forged rods
  • ARP main, head, and rod fasteners
  • Fire ring head gasket
  • Techtonics Tuning cams
  • VVT delete plate w/MCT chain tensioner
  • Performance engine bearings
  • Full Ferrea head package SS valves and dual springs titanium tensioners/ port polish
  • Garret GTX3584RS turbo
  • Krabifab custom made intake and exhaust manifolds
  • CTS fuel rail
  • Custom air box, plumbing, and FMIC
  • Custom cooling system swirl pot
  • Labed custom oil pan
  • Fabless motor mounts
  • Custom 3” exhaust to Magnaflow muffler

Driveline

4MOTION SYSTEM FROM MK4 R32
  • 02M 6 speed manual transmission with cryo gears and Wavetrac LSD
  • Clutch Masters FX850 Super Single Clutch
  • Haldex rear differential with Wavetrac LSD and Van der Veer Engineering controller
  • Custom fabricated rear tubular cradle for 4Motion all-wheel drive system
  • Fabless front control arms
  • Drive Shaft Shop axles front and rear to handle 1000HP
  • Scale Suspension adjustable coil overs custom made for this design and weight
  • Wilwood brakes

Wheels

BBS LM 090 17” converted to 3-piece 17x9
  • BBS LM 090 17” converted to 3-piece 17x9 -custom lips and barrels welded -full polish with black
    hardware and hidden filler valves -standard face mount in front, rear face mount in back
  • Toyo tires 205/40/17

Body

  • Shaved engine bay with Caddy tailgate “VOLKSWAGEN” frenched in on firewall
  • Front and rear wiper delete
  • Voomeran fender flares and side skirts
  • Body trim delete
  • Front side marker delete
  • Custom fuel filler to interior fuel cell
  • Zender rear spoiler
  • Shaved rear bumper
  • Custom made RS style front bumper
  • Electric rear pop out windows
  • Custom made badges
  • Hella smoked rear taillights
  • Smoked front headlights and French inners
  • Custom paint color

Interior

  • Recaro Trophy XL electric front seats recovered in black leather and centers in Relicate Spirit Of Le
    Mans Blue/Orange
  • Front and rear door cards recovered in black leather and Relicate Spirit Of Le Mans Blue/Orange
  • Dash covered in black leather with dual color stitching, featuring custom 3D printed bezel with custom
    controls and AIM digital dash
  • Custom made headliner and carpet
  • Custom made center console with phone charger, audio control, and rear window control
  • Custom audio system with 2 Focal Utopia 10” subs in custom window box with Focal 6.5 separates front
    and rear and Audiotec Fischer Helix amplifiers
